Accuracy

Geometric Correction

＜ 400℃

＞400℃

Response Time

95% reading

＜500ms

＜300ms

Ambient

Temperature

23℃±2℃

≥0℃ / ≥32℉

±1.5℃ or reading±5%

(±3℉ or reading±5%)

take large value)

±1℃ or reading±5%

(±2℉ or reading±5%)

take large value

＜-10℃ /＜14℉）

±3℃ / ±6℉

-10℃~0℃ / 14℉~32℉

±2℃ / ±4℉

Protection level (IP)

According to IEC 60529, the protection level is IP54

Drop test

3 meters

Vibrationand Shock protecion

IEC 60068-2-6，2.5g, 10 to 200Hz, IEC 60068-2-27, 50g

Laser safety

11mEN 61325-1:2006

Measuring distance

D:S=12:1 (measuring distance to target object)

Measuring condition

Vacuum medium

Spectral response

8 to 14 Micron

Emissivity

0.10 to 1.00 adjustable

Temperature coeffcient

±0.1℃/℉ or ±0.1% of reading, whichever is larger

Optical resolution

12:1 (when energy is 95% calculate )

Display resolution

 0.1℃ / 0.2℉

Repeatability (reading %)

Reading ±0.8% or 1.0℃/2， take the larger value

Auto power off time

approx. 6s

Sampling rate

≤ 0.5s

Backlight display function

√

Low battery indication

√

Data hold function

√

Max./Min./AVG./DIF. HOLD function

√

High/Lowtemperature Alarm function

√

Zero offset adjustment

√

Unit Symbol display

√

Max. display

3digits

Power supply

6F22, 9V  (extra heavy battery)

Battery life

10 hours when the laser and backlight are on.

Power consumption

≤50mW
