VC6243+ High Accuracy Digital Capacitance Inductance tests, Capacitor self-discharge (avoid burning the meter).
VC6243+ capacitance inductance meter, available to detect the tolerance value of capacitance and inductor, classification value, select accuracy value, measure the capacitance of cable, switch or printed circuit board circuit design, transformer winding, inductance coil, and inductance of various inductive components.
2000 digits display
2000 digits display
Technical Data:
|
Basic function |
Range |
Accuracy |
|
Capacitance |
2nF/20nF/200nF/2uF/20uF/2000uF |
±(2.0%+5) |
|
Inductance |
2mH/20mH/200mH/2H/20H |
Special Function:
|
Model |
VC6243+ |
|
Low battery indication |
Approx. less than 7.5V |
|
capacitor discharge protection |
√ |
|
Auto power off |
It will power off in 30 minutes if there is no measurement. |
|
Function protection |
√ |
|
Anti-shock protection |
√ |
|
Sampling rate |
3times/s |
|
Operation method |
Manual range |
|
Max. display |
1999 |
|
LCD size |
65× |
|
Battery |
9V ( |
|
Power consumption |
Quiescent current approx. 4mA |
